COB Neon Strip Manufacturer | Silicone Extruded Dotless COB Neon

COB Neon Strip Supplier & Manufacturer

Xmart provides end-to-end support for COB Neon Strip development and mass production. From COB light source selection to silicone extrusion, W12*H5mm dimension control, cable assembly and project packaging, our team helps lighting brands, distributors and project buyers build reliable slim dotless neon strip solutions.

COB + Silicone Integration

Combines COB dotless light output with a slim silicone extrusion body for premium visible lines.

W12*H5mm Dimension Control

One fixed finished size for stable sampling, quotation, installation planning and repeat orders.

Cable & Assembly Support

Custom cable exit, cable length, connector and end treatment for precise project installation.

OEM / ODM Support

Custom CCT, voltage, CRI, label, reel length, packaging and comprehensive project documentation.

What Is a COB Neon Strip?

A COB Neon Strip is a flexible linear light that uses a COB LED strip as the light source and encapsulates it inside a silicone extrusion body. Xmart COB Neon Strip has a fixed finished size of W12*H5mm, making it suitable for slim visible light lines where a standard LED neon flex profile may be too large.

Compared with a bare COB strip, COB Neon Strip provides a more finished neon-style appearance and added silicone surface protection. It is designed for visible decorative lines, not only hidden profile lighting.

W12*H5mm Silicone Extrusion Dotless COB Output Visible Linear Light

Width 12mm

Height 5mm

Why W12*H5mm Matters for COB Neon Strip

The W12*H5mm size gives the product a slim rectangular profile. It helps buyers plan installation space, mounting method, cable exit, packaging and repeat-order consistency before sampling.

Slim 5mm Height

Suitable for low-profile structures, shallow decorative spaces, and precise panel integrations.

12mm Visible Light Width

Creates a clean, bold visible linear light surface for compact neon-style applications.

Stable Specification

One fixed size makes architectural drawings, samples, quotation and repeat orders easier to control.

Compact Neon Alternative

Useful when the project needs a neon-style light line but larger standard LED neon flex profiles are too bulky.

COB Neon Strip vs Standard COB Strip

Comparison Items	COB Neon Strip	Standard COB Strip
Structure	COB strip inside silicone extrusion	Bare or coated flexible COB strip
Finished Size	W12*H5mm fixed silicone body	Depends on PCB width and coating
Visual Role	Visible neon-style light line	Usually hidden in profile, groove or cove
Protection	Silicone body gives surface protection and finished appearance	Depends on bare board, coating or external profile
Best For	Signage edges, furniture details, mirror lines, decorative outlines	General dotless linear lighting
Buyer Concern	Size fit, cable exit, mounting, end treatment	PCB width, wattage, CCT, CRI, profile fit

Conclusion: Choose COB Neon Strip when the light line itself will be visible and needs a slim silicone neon appearance. Choose standard COB Strip when the strip will be hidden inside a profile, groove or cove.

COB Neon Strip vs LED Neon Flex

Comparison Items	COB Neon Strip	LED Neon Flex
Light Source	COB light source	Usually SMD or other LED strip source with diffuser
Product Focus	Slim W12*H5mm compact neon-style line	Wider range of sizes, bending directions and outdoor profiles
Dotless Effect	COB light source supports smooth continuous output natively	Depends on LED density, diffuser and profile design
Best For	Slim signage, furniture, cabinet and mirror edge details	Larger architectural outlines, facades, signs and outdoor contours
Buyer Concern	Fixed size, cable exit, mounting method	Size, bending direction, IP rating, mounting accessories

Conclusion: Choose COB Neon Strip for compact slim visible lines. Choose LED Neon Flex when the project needs more size options, bending directions or larger architectural neon profiles.

How to Check If W12*H5mm COB Neon Strip Fits Your Project

Before sampling or mass production, verify these critical physical and installation requirements.

Available Space

Confirm the actual groove, channel or mounting area is larger than W12*H5mm.

Visible Light Surface

Confirm which side will face outward and how the light line will be viewed.

Cable Exit Direction

Confirm end cable, side cable or back cable direction before sampling.

Mounting Method

Confirm clips, channels, adhesive support or project-specific fixing method.

End Treatment

Confirm cut end, end cap, cable sealing and appearance requirement.

Bending Path

Confirm whether the installation needs straight lines, curves or corners.

COB Neon Strip Specifications

Product Type: COB Neon Strip

Light Source: COB LED strip

Finished Size: W12*H5mm (after extrusion)

Structure: Silicone extruded body

Visual Effect: Dotless continuous visible light

Profile Type: Slim rectangular neon strip

Color Options: Single color white / Custom

CCT / Voltage / Power: Confirm by Xmart datasheet

CRI: Confirm by datasheet / project

Cut Length: Confirm by circuit design

Cable Exit: Custom direction by project

Connector: Custom / Soldered option

Waterproof: Confirm by final end treatment

Mounting: Clips, channel or custom

OEM Support:

Label, cable, connector, reel length, packaging and datasheet customization supported.

* Note: Exact wattage, lumen output, IP rating or cut length must be confirmed via the official Xmart datasheet and sample testing for your specific configuration.

Where to Use COB Neon Strip

The compact W12*H5mm profile is ideal for visible linear accents where space is limited but a premium dotless appearance is required.

Retail Cabinet

High-end product presentation

Furniture Detail Lighting

Compact visible lines for cabinets, shelves, wardrobes and panels.

Cabinet Linear Accents

Slim visible lines for cabinet edges and display cabinet details.

Shelf & Display

Slim profile for tight shelving

Retail Display Structures

Clean light lines for showcases, counters and product display structures.

Interior Decorative Lines

Slim neon-style accents for walls, ceilings, bars, counters and feature areas.

Not Just a Strip. A Slim COB Neon Lighting System.

A COB Neon Strip should not be selected alone. It must match the driver, voltage, power, cable exit, mounting clip, installation space, end treatment and real project structure.

Size Matching

Confirm W12*H5mm fits the actual installation space perfectly.

Driver Matching

Confirm voltage, total power required and safety margin.

Cable Matching

Confirm cable direction, cable length and connector type.

Mounting Matching

Confirm clip, channel or custom installation method.

End Treatment

Confirm end cap, sealing and appearance requirements.

Application Matching

Confirm whether the line is used for signage, furniture, cabinet, mirror or architectural detail.

Custom COB Neon Strip for OEM / ODM Projects

Custom CCT

Warm white, neutral white, cool white or project-specific CCT.

Custom Voltage

Voltage should be confirmed based on circuit and project requirements.

Custom Cable Exit

End cable, side cable, back cable or project-specific cable direction.

Custom Connector

Soldered cable or connector solution according to installation needs.

Custom Mounting

Clip, channel or project-specific mounting support.

Custom End Treatment

End cap, sealing and cable assembly based on application.

Custom Packaging

Private label, reel label, datasheet, carton and brand packaging support.

What Buyers Should Confirm Before Sampling

Does W12*H5mm fit the installation space?
Will the light line be visible or hidden?
What CCT is required?
What voltage and wattage are required?
What cable exit direction is needed?
What mounting clip or channel will be used?
Does the project need straight lines, curves or corners?
Will the strip be factory-cut or cut on site?
What end treatment is required?
Is waterproof protection required?
Is dimming required?
Is OEM packaging required?

Common Problems in COB Neon Strip Projects

Problem: Product size does not fit the installation space

Solution: Confirm W12*H5mm dimension and mounting accessory size before sampling.

Problem: Buyer expects multiple sizes

Solution: Clarify that this specific product line focuses on one fixed W12*H5mm COB Neon Strip specification for consistency.

Problem: Cable exit conflicts with the structure

Solution: Confirm cable direction (end, side, back) and connector position before production.

Problem: End treatment affects appearance

Solution: Confirm end cap, sealing and cable assembly sample before bulk order to ensure aesthetic match.

Problem: The line is not straight after installation

Solution: Use matched clips, continuous aluminum channels or positioning guides for perfect straight lines.

Problem: Buyer confuses COB Neon Strip with LED Neon Flex

Solution: Explain that COB Neon Strip uses a COB light source and focuses specifically on one slim W12*H5mm silicone extrusion profile.

Related Products for Slim Neon and COB Lighting

COB LED Strip

Parent dotless COB light source category.

Slim COB Strip

For ultra-narrow bare COB installations.

Silicone LED Neon

Broader neon flex options and larger profiles.

Mirror LED Strip

For mirror and vanity lighting systems.

Cabinet LED Strip

For cabinet, shelf and furniture lighting.

LED Driver & Connectors

Stable power and wiring solutions.

FAQ About COB Neon Strip

What is a COB Neon Strip?

A COB Neon Strip combines a continuous dotless COB LED light source with a slim silicone extrusion body. It is designed to create a visible, smooth neon-style light line for compact architectural and decorative applications.

What size is Xmart COB Neon Strip?

This specific Xmart COB Neon Strip is manufactured to a fixed finished size of W12*H5mm after silicone extrusion. This standard size ensures stability for installation planning and repeat orders.

How is COB Neon Strip different from standard COB Strip?

Standard COB strips are usually bare or thinly coated and meant to be hidden inside profiles. A COB Neon Strip features a thicker W12*H5mm silicone body, making it durable and aesthetically pleasing enough to be installed visibly as a direct decorative line.

How is COB Neon Strip different from LED Neon Flex?

While both provide a neon effect, our COB Neon Strip specifically uses a COB light source in a highly compact W12*H5mm profile. Traditional LED Neon Flex often uses SMD LEDs with diffusers and comes in much larger, bulkier sizes for outdoor architecture.

Is COB Neon Strip dotless?

Yes. Because it uses a high-density COB LED core combined with the silicone extrusion, the output is completely smooth and dotless, even when viewed directly.

What should be confirmed before sampling?

Buyers must confirm that the W12*H5mm dimension fits their installation space. Additionally, required CCT, voltage, cable exit direction, and mounting method must be specified before we produce samples.

Can Xmart support OEM / ODM COB Neon Strip projects?

Yes. Xmart provides comprehensive OEM/ODM manufacturing. We can customize the CCT, cable direction, connectors, reel lengths, and provide private-label packaging for B2B brands and large project buyers.

Need a W12*H5mm COB Neon Strip for Your Project?

Tell us your installation space, CCT, voltage, wattage, cable direction, mounting method, cut length, end treatment, connector requirement and OEM packaging needs. Xmart can help configure a reliable COB Neon Strip solution for your project.
